响应面法优化酶-水连续提取西洋参须根人参皂苷

doi:10.3976/j.issn.1002-4026.20240113

Abstract

Abstract:

To optimize the extraction process for ginsenosides from the fibrous roots of American ginseng，the enzyme-water method was used for continuous extraction of ginsenosides from American ginseng. The total ginsenosides extraction yield was used as the evaluation index，and the extraction process was optimized using the response surface methodology. The results showed that the optimal enzymatic extraction conditions were as follows： α-amylase with an enzyme concentration of 7.3%，a liquid/solid ratio of 30 mL/g，and an enzymatic hydrolysis time of 1.2 h. After enzymatic hydrolysis，a secondary water extraction was performed，and the optimal conditions were as follows： a liquid/solid ratio of 27 mL/g，an extraction temperature of 89 ℃，and an extraction time of 1.3 h. Under these conditions，the total ginsenosides extraction yield reached 16.61%. Since it is stable，simple，and efficient，this method has significantly improved the extraction yield and avoided the waste of resources. It partially fills a gap in the extraction process of total ginsenosides from the fibrous roots of American ginseng and provides a reference for further purification，refinement，and activity studies of total ginsenosides.

Key words: American ginseng, fibrous roots, ginsenosides, extraction process, response surface methodology, single factor experiment, ultraviolet spectrophotometry

CLC Number:

R284.2

WANG Haiyan, YU Ping, WANG Xin, YU Hongxia, ZHOU Jie, FANG Lei. Optimization of enzyme-water continuous extraction of ginsenosides from fibrous roots of American ginseng using response surface methodology[J].Shandong Science, 2025, 38(5): 10-21.

Figures/Tables 17

Table 1

Table 2

Table 3

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Table 4

Table 5

Fig.6

Fig.7

Fig.8

Fig.9

Table 6

Table 7

Fig.10

References 26

[1]	于晓艳, 张宇弛, 方粟一, 等. 西洋参的化学成分和药理作用研究进展[J]. 中医药学报, 2024, 52(4):99-104. DOI:10.19664/j.cnki.1002-2392.240082
[2]	张燕停, 陆雨顺, 张悦, 等. 人参皂苷指纹图谱在山东产西洋参质量控制中的应用[J]. 药物分析杂志, 2024, 44(3): 512-521. DOI:10.16155/j.0254-1793.2024.03.17.
[3]	吕婧, 高燕, 李晨, 等. 基于斑马鱼模式生物的西洋参皂苷类成分增强免疫作用研究[J]. 中草药, 2020, 51(14): 3728-3733. DOI:10.7501/j.issn.0253-2670.2020.14.016.
[4]	张姝, 徐兰, 董泽洋, 等. 西洋参茎叶总皂苷对高血压心肌纤维化的影响及机制[J]. 中医临床研究, 2023, 15(9): 5-9. DOI:10.3969/j.issn.1674-7860.2023.09.002.
[5]	郑维维, 张珊, 唐彧, 等. 基于CCL20/CCR6探讨人参皂苷Rh₁调控乳腺癌细胞外渗的作用机制[J]. 中国药理学与毒理学杂志, 2021, 35(10): 756-757. DOI:10.3867/j.issn.1000-3002.2021.10.068.
[6]	高钧, 卢守四, 张蕾, 等. 人参皂苷Re促进胰高血糖素样肽-1分泌的研究[J]. 中国药物与临床, 2011, 11(12): 1383-1385. DOI:10.3969/j.issn.1671-2560.2011.12.008.
[7]	吕世鑫, 田潇然, 王洪涛, 等. 西洋参不定根总皂苷的响应面优化提取工艺及抗氧化活性研究[J]. 食品科技, 2019, 44(9): 248-254. DOI:10.13684/j.cnki.spkj.2019.09.044.
[8]	马晓宁, 柴瑞华, 赵余庆. 西洋参茎叶皂苷水解产物中稀有抗肿瘤成分的化学研究[J]. 中草药, 2008, 39(9): 1291-1294. DOI:10.3321/j.issn:0253-2670.2008.09.004.
[9]	FAN S H, ZHAO F J, ZHANG J G, et al. American ginseng root rot caused by Fusarium redolens in China[J]. Plant Disease, 2021. DOI:10.1094/PDIS-12-20-2600-PDN.
[10]	ZHANG X K, ZHANG G S, TIAN L X, et al. Ecological regulation network of quality in American ginseng: Insights from macroscopic-mesoscopic-microscopic perspectives[J]. Industrial Crops and Products, 2023, 206: 117617. DOI:10.1016/j.indcrop.2023.117617.
[11]	毛英民, 于文杰, 李佳奇, 等. HPLC结合化学计量法对西洋参不同部位中人参皂苷的差异分析[J]. 中华中医药学刊, 2023, 41(1):165-170. DOI:10.13193/j.issn.1673-7717.2023.01.037.
[12]	郝岩, 王英平, 张志东, 等. 西洋参不同部位皂苷成分差异性分析[J]. 中药材, 2023, 46(5): 1177-1187. DOI:10.13863/j.issn1001-4454.2023.05.020.
[13]	张大军, 王兆华. 正交试验法优选人参天麻颗粒的水提工艺[J]. 山东化工, 2021, 50(8): 7-9. DOI:10.19319/j.cnki.issn.1008-021x.2021.08.005.
[14]	陈丹燕, 余欣彤, 彭帮贵, 等. 多指标正交试验法优选红参水提工艺研究[J]. 亚太传统医药, 2021, 17(10): 42-45. DOI:10.11954/ytctyy.202110012.
[15]	杨雨, 郑斯文, 金银萍, 等. 人参皂苷的提取分离方法研究进展[J]. 江苏农业科学, 2014, 42(5): 214-217. DOI:10.15889/j.issn.1002-1302.2014.05.118.
[16]	李娅丽. 动态微波提取人参皂苷及多糖[D]. 武汉: 武汉工程大学, 2015.
[17]	林花, 王欣宇, 金龙哲, 等. 碱水超声法提取二醇型人参皂苷工艺研究[J]. 山东化工, 2022, 51(7): 40-42. DOI:10.3969/j.issn.1008-021X.2022.07.013.
[18]	张廉高. 三七、西洋参皂苷的分离提取工艺研究及丰产皂苷Rg₁、Rb₁的结构修饰[D]. 昆明: 云南大学, 2017. DOI:10.27456/d.cnki.gyndu.2017.000065.
[19]	宋齐. 人参主要化学成分及皂苷提取方法研究进展[J]. 人参研究, 2019, 31(4): 43-46. DOI:10.19403/j.cnki.1671-1521.2019.04.013.
[20]	王红坤, 颜岳衡, 何金铭, 等. 东北刺人参总皂苷提取工艺的优化及睡眠-觉醒节律调节作用研究[J]. 食品安全质量检测学报, 2023, 14(5): 283-291.
[21]	戴浩. 人参有效成分的提取方式、成分鉴定及抗氧化活性研究[D]. 武汉: 华中农业大学, 2020. DOI:10.27158/d.cnki.ghznu.2020.001215.
[22]	居秀荣, 李加友, 于建兴, 等. 酶辅助提取植物天然活性物质的研究进展[J]. 食品研究与开发, 2024, 45(9):202-211. DOI:10.12161/j.issn.1005-6521.2024.09.027.
[23]	RAGHU H S, RAJESHWARA N A. American ginseng root rot caused by Fusarium redolens in China[J]. International Food Research Journal, 2015, 22(2): 869-871. DOI:10.1094/pdis-12-20-2600-pdn.
[24]	AGGERJ, VIKSØ-NIELSENA, MEYER A S. Enzymatic xylose release from pretreated corn bran Arabinoxylan: Differential effects of deacetylation and deferuloylation on insoluble and soluble substrate fractions[J]. Journal of Agricultural and Food Chemistry, 2010, 58(10): 6141-6148. DOI:10.1021/jf100633f. pmid: 20411987
[25]	李俊, 杜文娟, 高天慧, 等. 葫芦七总黄酮超声辅助提取工艺优化[J]. 中成药, 2024, 46(4):1319-1322. DOI:10.3969/j.issn.1001-1528.2024.04.040.
[26]	XU T, LIN H Y, et al. Comprehensive quality evaluation of American ginseng for different parts and abnormal trait based on the major ginsenoside contents and morphological characteristics[J]. BioMed Research International, 2021, 2021: 8831080. DOI:10.1155/2021/8831080.

条件	α-淀粉酶	木瓜蛋白酶
液料比/（mL·g^-1）	7	5
酶解温度/℃	85	55
酶解时间/h	2	4
加酶量/%	2.0	0.4

水平	因素
水平	A加酶量/%	B液料比/（mL·g^-1）	C酶解时间/h
-1	5	20	0.5
0	7	25	1.0
1	9	30	1.5

水平	因素
水平	A液料比	B提取温度/℃	C提取时间/h
-1	20	70	0.5
0	25	80	1.0
1	30	90	1.5

实验号	A液料比	B提取温度	C提取时间	Y总皂苷提取率/%
1	-1	-1	0	12.01
2	1	-1	0	12.45
3	-1	1	0	14.16
4	1	1	0	14.17
5	-1	0	-1	13.16
6	1	0	-1	12.51
7	-1	0	1	12.67
8	1	0	1	13.89
9	0	-1	-1	12.51
10	0	1	-1	13.61
11	0	-1	1	12.81
12	0	1	1	14.43
13	0	0	0	14.56
14	0	0	0	14.41
15	0	0	0	14.21
16	0	0	0	14.49
17	0	0	0	14.32

来源	离均差平方和	自由度	均方	F	P	显著性
模型	12.290	9	1.370	38.24	<0.000 1	**
A	0.130	1	0.130	3.64	0.098 0
B	5.430	1	5.430	152.00	<0.000 1	**
C	0.510	1	0.510	14.14	0.007 1	**
AB	0.046	1	0.046	1.29	0.292 7
AC	0.870	1	0.870	24.48	0.001 7	**
BC	0.068	1	0.068	1.89	0.211 3
A²	2.320	1	2.320	64.82	<0.000 1	**
B²	0.890	1	0.890	24.84	0.001 6	**
C²	1.510	1	1.510	42.30	0.000 3	**
残差	0.250	7	0.036
失拟项	0.170	3	0.058	3.04	0.155 6
纯误差	0.076	4	0.019
总和	12.540	16

Optimization of enzyme-water continuous extraction of ginsenosides from fibrous roots of American ginseng using response surface methodology

RichHTML

PDF (PC)

Like

Knowledge

Abstract

Cite this article

share this article

Figures/Tables 17

References 26

Related Articles 15

Metrics

Comments

Recommended 0

实验号	A液料比	B提取温度	C提取时间	Y总皂苷提取率/%
1	-1	-1	0	14.91
2	1	-1	0	15.43
3	-1	1	0	15.48
4	1	1	0	15.75
5	-1	0	-1	14.82
6	1	0	-1	15.53
7	-1	0	1	15.47
8	1	0	1	15.79
9	0	-1	-1	14.94
10	0	1	-1	15.58
11	0	-1	1	15.48
12	0	1	1	15.81
13	0	0	0	15.68
14	0	0	0	15.57
15	0	0	0	15.63
16	0	0	0	15.59
17	0	0	0	15.63

来源	离均差平方和	自由度	均方	F	P	显著性
模型	1.430	9	0.160	63.12	<0.0001	**
A	0.410	1	0.410	164.21	<0.000 1	**
B	0.430	1	0.430	175.51	<0.000 1	**
C	0.350	1	0.350	139.92	<0.000 1	**
AB	0.016	1	0.016	6.20	0.041 6	*
AC	0.038	1	0.038	15.08	0.006 0	**
BC	0.024	1	0.024	9.53	0.017 6	*
A²	0.081	1	0.081	32.15	0.000 8	**
B²	0.033	1	0.033	13.15	0.008 4	**
C²	0.026	1	0.026	10.36	0.014 7	*
残差	0.018	7	2.521×10^-3
失拟项	0.010	3	3.483×10^-3	1.94	0.265 7
纯误差	7.20×10^-3	4	1.800×10^-3
总和	1.450	16
