称重式降水传感器测量误差变化研究

doi:10.3976/j.issn.1002-4026.2023.01.016

Abstract

Abstract:

This paper proposes a field calibration method via standard weights accumulation to study the variation trend of the measurement error of the weighing precipitation sensor in an automatic meteorological station. Herein, the field calibration data of sensors from 2019 to 2021 are analyzed. Further, a calculation method is presented for measuring the error deviation degree and its variation trend with respect to the weighing precipitation sensor. The variation model of sensor deviation is obtained on the basis of the historical calibration data. The results show that the measurement error range and observation data quality are controllable. The overall deviation degree of the sensor is 2.1% of the standard value and its increase is 0.1% per year. This study can provide reference for predicting measurement errors and durability of meteorological sensors.

Key words: weighing precipitation sensor, measurement error, field calibration, deviation degree

CLC Number:

P414.9

QIU Shi, YANG Maoshui, SUN Yan, REN Yan, WU Juxiu. Research on measurement error variation of a weighing precipitation sensor[J].Shandong Science, 2023, 36(1): 124-130.

Figures/Tables 9

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Table 1

Table 2

References 12

[1]	SANTANA M A A, GUIMARÃES P L O, LANZA L G, et al. Metrological analysis of a gravimetric calibration system for tipping-bucket rain gauges[J]. Meteorological Applications, 2015, 22: 879-885. DOI:10.1002/met.1540. doi: 10.1002/met.1540
[2]	LEEPER R D, KOCHENDORFER J. Evaporation from weighing precipitation gauges: Impacts on automated gauge measurements and quality assurance methods[J]. Atmospheric Measurement Techniques, 2015, 8(6): 2291-2300. DOI:10.5194/amt-8-2291-2015. doi: 10.5194/amt-8-2291-2015
[3]	李林, 范雪波, 崔炜, 等. 称重与人工观测降水量的差异[J]. 应用气象学报, 2015, 26(6): 688-694.
[4]	吴宜, 刘西川, 张军, 等. Parsivel激光雨滴谱仪与雨量计观测降水的一致性分析[J]. 气象科技, 2020, 48(2): 147-153. DOI:10.19517/j.1671-6345.20190170. doi: 10.19517/j.1671-6345.20190170
[5]	徐灵杰. 基于视频分析的雨量计设计[D]. 南京: 南京信息工程大学, 2020.
[6]	姚宇. 高稳定光学雨量计的研究[D]. 南京: 南京信息工程大学, 2021.
[7]	李朋军. 称重式雨量计与虹吸雨量计降水数据对比分析[J]. 水科学与工程技术, 2020(2): 11-13. DOI:10.19733/j.cnki.1672-9900.2020.02.03. doi: 10.19733/j.cnki.1672-9900.2020.02.03
[8]	HASELOW L, MEISSNER R, RUPP H, et al. Evaluation of precipitation measurements methods under field conditions during a summer season: A comparison of the standard rain gauge with a weighable lysimeter and a piezoelectric precipitation sensor[J]. Journal of Hydrology, 2019, 575: 537-543. DOI:10.1016/j.jhydrol.2019.05.065. doi: 10.1016/j.jhydrol.2019.05.065
[9]	陈志超, 迟庆红. DSC1型称重式降水传感器典型问题及维护[J]. 自动化与仪器仪表, 2022(3): 222-224. DOI:10.14016/j.cnki.1001-9227.2022.03.222. doi: 10.14016/j.cnki.1001-9227.2022.03.222
[10]	郑亮, 黄小静, 刘宗庆, 等. 双翻斗雨量传感器翻斗误差的分析[J]. 计量与测试技术, 2018, 45(1): 119-120. DOI:10.15988/j.cnki.1004-6941.2018.01.045. doi: 10.15988/j.cnki.1004-6941.2018.01.045
[11]	SAVINA M, SCHÄPPI B, MOLNAR P, et al. Comparison of a tipping-bucket and electronic weighing precipitation gage for snowfall[J]. Atmospheric Research, 2012, 103: 45-51. DOI:10.1016/j.atmosres.2011.06.010. doi: 10.1016/j.atmosres.2011.06.010
[12]	倾鹏程, 蔡成满, 吴卓宣. 称重雨量计与双翻斗雨量计的对比分析[J]. 广东气象, 2018, 40(2): 69-72.

校准点	1	2	3	4	5	6	7
标准值	1.0	10.0	30.0	50.0	81.8	241.1	400.3
平均偏离程度	2.1%	0.9%	0.5%	0.5%	0.4%	0.5%	0.4%

校准点	1	2	3	4	5	6	7
标准值	1.0	10.0	30.0	50.0	81.8	241.1	400.3
偏离程度年变化率	0	0	0	0.10%	0.06%	0.04%	0.06%
