基于小波变换与改进时间序列模型的船舶升沉运动预测方法

doi:10.3976/j.issn.1002-4026.20240019

Abstract

Abstract:

Lag in detecting ship heave motion signals severely affects the performance of ocean heave compensation systems. Therefore, accurate heave motion prediction can effectively improve the stability and real-time performance of these systems. To improve the engineering practicability of a heave motion prediction model, we designed an autoregressive time-series model featuring high calculation efficiency, simple programing, and a small accumulation error. Moreover, to further address the poor adaptability of the model to nonlinear and nonstationary complex sea conditions and long-term predictions, we developed a combined prediction model based on wavelet transform and improved autoregression using the wavelet multiscale analysis method and achieved online multistep prediction of heave motions by decomposing and transforming historical data, reconstructing sub-sequence prediction, and forecasting data synthesis. Finally, theoretical testing and experiments were conducted on stationary random waveforms and nonstationary waveforms measured on ships. The analysis results show that the combined model exhibits good prediction performance and can effectively reduce the control error of the ocean heave compensation system caused by the lag in the heave motion signal detection.

Key words: ocean engineering, heave compensation, time-series prediction, wavelet transformation

CLC Number:

TE58

LIU Zhizhen, HUANG Lumeng, SUN Yapeng, ZHANG Ying, LIU Zhendong. Ship heave motion prediction method based on wavelet transform and improved time series model[J].Shandong Science, 2024, 37(6): 1-11.

Figures/Tables 12

Fig.1

Fig.2

Table 1

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

Table 2

Fig.8

Fig.9

Fig.10

References 21

[1]	李欢, 樊春明, 李鹏, 等. 浮式波浪补偿装置研究及发展建议[J]. 石油机械, 2022, 50(2): 53-58. DOI: 10.16082/j.cnki.issn.1001-4578.2022.02.008.
[2]	WOODACRE J K, BAUER R J, IRANI R. Hydraulic valve-based active-heave compensation using a model-predictive controller with non-linear valve compensations[J]. Ocean Engineering, 2018, 152: 47-56. DOI: 10.1016/j.oceaneng.2018.01.030.
[3]	LIU Z D, ZHANG Y T, YU X G, et al. Study on the control strategies of offshore drilling crown-block heave compensation system with compound cylinders[J]. IEEE Access, 2020, 8: 149270-149281. DOI: 10.1109/access.2020.3015720.
[4]	CHEN S L, XIE P, LIAO J H, et al. NMPC-PID control of secondary regulated active heave compensation system for offshore crane[J]. Ocean Engineering, 2023, 287: 115902. DOI: 10.1016/j.oceaneng.2023.115902.
[5]	ZINAGE S, SOMAYAJULA A. Deep reinforcement learning based controller for active heave compensation[J]. IFAC-PapersOnLine, 2021, 54(16): 161-167. DOI: 10.1016/j.ifacol.2021.10.088.
[6]	黄鲁蒙, 张彦廷, 孙选建, 等. 海洋浮式钻井液压绞车升沉补偿系统设计[J]. 石油学报, 2017, 38(9): 1091-1098. DOI: 10.7623/syxb201709011.
[7]	LI S Z, WEI J H, GUO K, et al. Nonlinear robust prediction control of hybrid active-passive heave compensator with extended disturbance observer[J]. IEEE Transactions on Industrial Electronics, 2017, 64(8): 6684-6694. DOI: 10.1109/tie.2017.2698358.
[8]	HE Y H, ZHAO Y X, HAN X, et al. Functional risk-oriented health prognosis approach for intelligent manufacturing systems[J]. Reliability Engineering & System Safety, 2020, 203: 107090. DOI: 10.1016/j.ress.2020.107090.
[9]	DUAN W Y, HAN Y, HUANG L M, et al. A hybrid EMD-SVR model for the short-term prediction of significant wave height[J]. Ocean Engineering, 2016, 124: 54-73. DOI: 10.1016/j.oceaneng.2016.05.049.
[10]	JIANG H, DUAN S L, HUANG L M, et al. Scale effects in AR model real-time ship motion prediction[J]. Ocean Engineering, 2020, 203: 107202. DOI: 10.1016/j.oceaneng.2020.107202.
[11]	KHAN A, BIL C, MARION K E. Ship motion prediction for launch and recovery of air vehicles[C]//Proceedings of OCEANS 2005 MTS/IEEE. Washington, DC, USA: IEEE, 2005:2795-801. DOI: 10.1109/oceans.2005.1640198.
[12]	SHI B H, XIAN L, WU Q P, et al. Active heave compensation prediction research for deep sea homework crane based on KPSO-SVR[C]//Proceedings of the 33rd Chinese Control Conference. Nanjing: IEEE, 2014: 977-982. DOI: 10.1109/chicc.2014.6896273.
[13]	HUANG L M, DENG X G, BO Y C, et al. Evolutionary optimization assisted delayed deep cycle reservoir modeling method with its application to ship heave motion prediction[J]. ISA Transactions, 2022, 126: 638-648. DOI: 10.1016/j.isatra.2021.08.020.
[14]	ZHANG R. Statistical analysis of the non-stationary binomial AR(1) model with change point[J]. Applied Mathematical Modelling, 2023, 118: 152-165. DOI: 10.1016/j.apm.2023.01.032.
[15]	刘自强, 王效岳, 白如江. 基于时间序列模型的研究热点分析预测方法研究[J]. 情报理论与实践, 2016, 39(5): 27-33. DOI: 10.16353/j.cnki.1000-7490.2016.05.006.
[16]	YE F, YUAN Y B. A modified stochastic model for LS+AR hybrid method and its application in polar motion short-term prediction[J]. Geodesy and Geodynamics, 2024, 15(1): 100-105. DOI: 10.1016/j.geog.2023.05.005.
[17]	陈是扦, 彭志科, 周鹏. 信号分解及其在机械故障诊断中的应用研究综述[J]. 机械工程学报, 2020, 56(17): 91-107. DOI: 10.3901/JME.2020.17.091.
[18]	白润才, 柴森霖, 刘光伟, 等. 基于Mallat算法与ARMA模型的露天矿卡车故障率预测[J]. 中国安全科学学报, 2018, 28(10): 31-37. DOI: 10.16265/j.cnki.issn1003-3033.2018.10.006.
[19]	赵紫龙. 基于小波分解的差分灰色神经网络-AR模型及其在地铁隧道沉降预测中应用研究[J]. 测绘通报, 2020(S1): 99-103. DOI: 10.13474/j.cnki.11-2246.2020.0523.
[20]	高迪驹, 潘康凯, 王天真. 混合动力船舶负载功率预测模型研究[J]. 控制工程, 2019, 26(2): 362-367. DOI: 10.14107/j.cnki.kzgc.161443.
[21]	张彦廷, 黄鲁蒙, 陈国明, 等. 深水钻井补偿绞车的节能机理及解耦控制方案研究[J]. 中国石油大学学报(自然科学版), 2017, 41(4): 124-131. DOI: 10.3969/j.issn.1673-5005.2017.04.016.

预测步数	随机波			实测波
预测步数	δ_MAE/m	δ_RMSE/m	J_D	δ_MAE/m	δ_RMSE/m	J_D
1	0.000 1	0.000 2	0.999 8	0.035 0	0.056 3	0.902 0
3	0.007 1	0.008 3	0.990 4	0.150 2	0.210 5	0.572 5
5	0.047 7	0.055 9	0.935 0	0.230 1	0.303 2	0.332 5

预测步数	δ_MAE/m	δ_RMSE/m	J_D
1	0.000 2	0.000 3	0.999 3
3	0.005 6	0.007 9	0.94 2
5	0.015 5	0.020 2	0.955 0
