新型本征二维GeO2对SF6分解气体的吸附及电子特性研究

doi:10.3976/j.issn.1002-4026.20240038

Abstract

Abstract:

SF₆ is widely used in high-voltage insulated equipment due to its excellent insulating properties. High-voltage insulated equipment faces the problem of insulation aging during its long-term operation, which can reduce the stability and safety of energy power equipment. When partial discharge occurs, SF₆ decomposes under high-voltage and temperature into various species, such as SO₂, SO₂F₂, HF, and H₂S. Based on the first principle, a novel two-dimensional semiconductor pristine GeO₂ monomolecular layer, which has a strong adsorption capacity for SF₆decomposed gases, is proposed in this study. Results show that this pristine GeO₂ monomolecular layer provides an ideal amount of charge transfer and work function during the adsorption process. The detection of the SF₆ decomposed gases by the novel two-dimensional GeO₂, which is a gas-sensitive semiconductor material, allows us to identify the operational status and degree of insulation of high-voltage insulated equipment, which is crucial for maintaining the reliability and stability of power systems.

Key words: density functional theory, adsorption mechanism, GeO₂, SF₆decomposed gases, electronic properties

CLC Number:

O469

YANG Le, SUN Wanwan, DING Lishun, ZENG Wentian. Adsorption of SF₆decomposed gases and its electronic properties on a novel pristine two-dimensional GeO₂[J].Shandong Science, 2024, 37(6): 75-82.

Figures/Tables 7

Fig.1

Fig.2

Fig.3

Fig.4

Fig.5

Fig.6

Fig.7

References 25

[1]	任志刚, 潘泽华, 郭卫, 等. 纳米掺杂对环氧复合绝缘材料不均匀热老化特性的影响[J]. 绝缘材料, 2023, 56(12): 92-97. DOI: 10.16790/j.cnki.1009-9239.im.2023.12.012.
[2]	宴年平, 于钦学, 曹淳枫, 等. SF₆电力设备局部放电与分解气体组分关系的研究进展[J]. 绝缘材料, 2013, 46(5): 1-3. DOI: 10.16790/j.cnki.1009-9239.im.2013.05.001.
[3]	顾琦, 仲林林. 基于一维电弧模型的SF₆混合气体灭弧性能评价[J]. 电力工程技术, 2022, 41(6): 140-146. DOI: 10.12158/j.2096-3203.2022.06.017.
[4]	王胜辉, 刘华琦, 耿辉, 等. 环氧树脂与聚四氟乙烯表面性能的研究[J]. 绝缘材料, 2023, 56(7): 16-20. DOI: 10.16790/j.cnki.1009-9239.im.2023.07.003.
[5]	董晓虎, 林磊, 何相升, 等. 基于红外复合光学原理的SF₆气体分解产物现场检测方法[J]. 现代电子技术, 2023, 46(1): 64-68. DOI: 10.16652/j.issn.1004-373x.2023.01.013.
[6]	周海龙, 魏存金, 金佳美, 等. SF₆/N₂混合气体综合检测技术研究[J]. 电工技术, 2024(6): 194-197. DOI: 10.19768/j.cnki.dgjs.2024.06.056.
[7]	石琳, 米丰, 曾季东, 等. 基于差分光声光谱法的SF₆气体泄漏故障检测及预警[J]. 微型电脑应用, 2024, 40(3): 149-153.
[8]	程绳, 王身丽, 董晓虎, 等. 基于中红外TDLAS的SF₆、H₂S背景下SO₂浓度检测[J]. 分析仪器, 2024(1): 52-57.
[9]	宋东波, 黄洁, 金甲杰, 等. 红外成像检漏技术在GIS SF₆气体泄漏检测中的应用[J]. 安徽电气工程职业技术学院学报, 2023, 28(1): 52-56. DOI: 10.3969/j.issn.1672-9706.2023.01.008.
[10]	汪沨, 邱毓昌, 张乔根. 六氟化硫混合气体绝缘的发展动向[J]. 绝缘材料, 2002, 35(5): 31-34. DOI: 10.16790/j.cnki.1009-9239.im.2002.05.010.
[11]	SCHAIBLEY J R, YU H Y, CLARK G, et al. Valleytronics in 2D materials[J]. Nature Reviews Materials, 2016, 1(11): 16055. DOI: 10.1038/natrevmats.2016.55.
[12]	ZHANG Q F, GUI Y G, QIAO H, et al. Theoretical study of SF₆ decomposition products adsorption on metal oxide cluster-modified single-layer graphene[J]. Journal of Industrial and Engineering Chemistry, 2022, 105: 278-290. DOI: 10.1016/j.jiec.2021.09.025.
[13]	ZHOU T F, PANG W K, ZHANG C F, et al. Enhanced sodium-ion battery performance by structural phase transition from two-dimensional hexagonal-SnS₂ to orthorhombic-SnS[J]. ACS Nano, 2014, 8(8): 8323-8333. DOI: 10.1021/nn503582c.
[14]	KOTEESWARA REDDY N, DEVIKA M, GOPAL E S R. Review on tin (II) sulfide (SnS) material: synthesis, properties, and applications[J]. Critical Reviews in Solid State and Materials Sciences, 2015, 40(6): 359-398. DOI: 10.1080/10408436.2015.1053601.
[15]	REDDY K T R, REDDY N K, MILES R W. Photovoltaic properties of SnS based solar cells[J]. Solar Energy Materials and Solar Cells, 2006, 90(18/19): 3041-3046. DOI: 10.1016/j.solmat.2006.06.012.
[16]	WANG G Y, ZHENG K, HUANG Y X, et al. An investigation of the positive effects of doping an Al atom on the adsorption of CO₂ on BN nanosheets: a DFT study[J]. Physical Chemistry Chemical Physics, 2020, 22(17): 9368-9374. DOI: 10.1039/D0CP00714E.
[17]	CUI H, ZHANG X X, ZHANG J, et al. Adsorption behaviour of SF₆ decomposed species onto Pd₄-decorated single-walled CNT: a DFT study[J]. Molecular Physics, 2018, 116(13): 1749-1755. DOI: 10.1080/00268976.2018.1451930.
[18]	BO Z, GUO X Z, WEI X, et al. Density functional theory calculations of NO₂ and H₂S adsorption on the group 10 transition metal (Ni, Pd and Pt) decorated graphene[J]. Physica E: Low-Dimensional Systems and Nanostructures, 2019, 109: 156-163. DOI: 10.1016/j.physe.2019.01.012.
[19]	QIAN H, DENG J, ZHOU H B, et al. First-principles study of Pd-MoSe₂ as sensing material for characteristic SF₆ decomposition components[J]. AIP Advances, 2019, 9(12): 125013. DOI: 10.1063/1.5128831.
[20]	CUI H, ZHANG G Z, ZHANG X X, et al. Rh-doped MoSe₂ as a toxic gas scavenger: a first-principles study[J]. Nanoscale Advances, 2019, 1(2): 772-780. DOI: 10.1039/c8na00233a.
[21]	CUI H, ZHU H L, JIA P F. Adsorption and sensing of SO₂ and SOF₂ molecule by Pt-doped HfSe₂ monolayer: a first-principles study[J]. Applied Surface Science, 2020, 530: 147242. DOI: 10.1016/j.apsusc.2020.147242.
[22]	GAO R L, YONG Y L, HU S, et al. Adsorption and gas-sensing performance of SF₆ decomposition gases on GeS monolayers with and without single vacancies and Si-doping[J]. Applied Surface Science, 2021, 568: 150961. DOI: 10.1016/j.apsusc.2021.150961.
[23]	洪长翔. 氧化锌基甲烷气体传感器检测特性及气敏机理第一性原理研究[D]. 重庆: 西南大学, 2018.
[24]	蒋庆明, 张艳妹, 王明祥, 等. SF₆分解组分的气体传感器检测方法综述[J]. 绝缘材料, 2024, 57(3): 1-14. DOI: 10.16790/j.cnki.1009-9239.im.2024.03.001.
[25]	桂银刚. 金属掺杂碳纳米管传感器检测六氟化硫分解产物的气敏特性研究[D]. 重庆: 重庆大学, 2017.
