基于换层方式的具有有限缓冲区的动态双层网络的交通动态

孙明明,凌翔*

  1. 合肥工业大学 汽车与交通工程学院,安徽 合肥,230009
  • 收稿日期:2024-11-21 接受日期:2025-01-30 上线日期:2025-09-02
  • 通信作者: 凌翔 E-mail: lingxiang@hfut.edu.cn
  • 作者简介:孙明明(1998—),女,硕士研究生,研究方向为复杂网络。E-mail:2170337620@qq.com
  • 基金资助:
     国家自然科学基金项目(52472312)

Traffic dynamics of a finite-buffer two-layer network via layer-switching mechanisms

SUN Mingming, LING Xiang*

  1. College of Automotive and Transportation Engineering, Hefei University of Technology, Hefei, 230009, China
  • Received:2024-11-21 Accepted:2025-01-30 Published:2025-09-02
  • Contact: LING Xiang E-mail: lingxiang@hfut.edu.cn

摘要: 为了缓解双层网络中底层网络节点的排队长度,减少信息包在传输过程的旅行时间,可以通过信息包在两层网络间传输提升网络的整体流量和传输效率。研究了动态和静态耦合网络在有限的缓存区间下,基于信息包在两层网络间判断换层的频次不同,信息包产生率和网络的耦合强度对改善网络传输能力和稳定性的影响。该论文通过分析丢包率、密度和平均旅行时间来比较两种换层方式的运行效率,采用损失阈值来衡量两种换层方式下网络的稳定可靠性。结果表明在具有有限缓冲区间的双层动态网络中,换层方式和换层概率影响网络的传输效率,通过联合换层方式和网络间的连边数能使网络的损失阈值增大,使网络中信息包稳定传输的能力优化,缓解网络拥堵。

关键词: 双层网络, 动态网络, 换层概率, 损失阈值, 信息包产生率, 缓冲区间

Abstract: To alleviate queue lengths at bottom nodes in two-layer networks, reduce data packet travel time, and improve overall network traffic efficiency, this paper examines information packet transfer mechanisms between network layers. The study investigates how layer judgment frequency and network coupling strength influence transmission capability and stability in dynamic and static coupled networks with limited cache capacity. We compare the operational efficiency of two layer-switching approaches by analyzing packet loss rates, traffic density, and average travel times. Network stability and reliability are measured using loss threshold values. Results indicate that in two-layer dynamic networks with limited buffer space, both the layer-switching methodology and switching probability significantly affect transmission efficiency. By jointly optimizing the layer-switching approach and inter-layer edge distribution, the network’s loss threshold can be increased, enhancing stable information transmission capacity and alleviating network congestion.

Key words: Two-layer network, dynamic network, layer-switching probability, loss threshold, packet generation rate, buffer

中图分类号:

  • U491.13
