黄芪-白茅根治疗慢性肾小球肾炎作用机制的可视化分析

doi:10.3976/j.issn.1002-4026.2022.04.008

摘要/Abstract

摘要：

运用数据库及可视化软件分析黄芪-白茅根治疗慢性肾小球肾炎(chronic glomerulonephritis,CGN)的有效活性成分并探讨其潜在作用机制。通过中药系统药理学数据库与分析平台及BATMAN-TCM数据库收集黄芪-白茅根活性成分,SwissTargetPrediction和Uniprot数据库进行靶点标准化处理;通过GeneCards、OMIM、DisGeNET、Drugbank、DiGSeE数据库筛选CGN相关靶点;应用 Cytoscape软件构建相关网络图;利用Omicshare平台进行基因本体(gene ontology, GO)和京都基因与基因组百科全书(Kyoto encyclopedia of genes and genomes, KEGG)分析;采用AutoDock Vina及LigPlot进行核心成分与核心靶点的对接。黄芪-白茅根中共筛选出27个活性成分和271个活性成分靶点。对143个药物和疾病的交集靶点进行分析,获得7 084个GO相关过程,230个KEGG信号通路,其中差异的有4 663个GO相关过程,159个KEGG信号通路。分子对接发现本研究筛选的核心成分与靶点拥有较好的结合能。研究表明黄芪-白茅根是通过多成分、多靶点、多通路的作用方式发挥治疗CGN的作用,为CGN的治疗提供了重要的科学依据。

关键词: 黄芪, 白茅根, 慢性肾小球肾炎, 网络药理学, 分子对接

Abstract:

Database and visualization software were employed to analyze the active ingredients of Astragali Radix-Imperatae Rhizomain in the treatment of chronic glomerulonephritis (CGN) and explore the potential underlying mechanism. The active ingredients of Astragali Radix-Imperatae Rhizomain were collected using Traditional Chinese Medicine system pharmacology databases and analysis platforms and BATMAN-TCM databases, and the target information was standardized using SwissTargetPrediction and Uniprot databases. CGN-related targets were screened using the GeneCards, OMIM, DisGeNET, Drugbank, and DiGSeE databases. Relevant network diagrams were constructed using Cytoscape software. Gene ontology (GO) and Kyoto encyclopedia of genes and genomes (KEGG) analyses were performed using the Omicshare platform. AutoDock Vina and LigPlot were used for molecular docking of the core components to the core targets. A total of 27 active ingredients and 271 active ingredient targets were screened from Astragali Radix-Imperatae Rhizomain. The analysis of 143 drug and disease intersection targets yielded 7 084 GO-related processes and 230 KEGG signaling pathways, of which 4 663 GO-related processes and 159 KEGG signaling pathways were differentially identified. Further validation by molecular docking revealed that the core components were able to bind better to the core targets. Astragali Radix-Imperatae Rhizomain were found to exert their effect on the treatment of CGN through a multi-ingredient, multi-target, and multi-pathway mode of action, providing important scientific information for the treatment of CGN.

Key words: Astragali Radix, Imperatae Rhizomain, chronic glomerulonephritis, network pharmacology, molecular docking

中图分类号:

R285

祝晓丽, 高家荣, 施苗苗, 秦秀娟, 魏良兵, 刘涛, 张魏. 黄芪-白茅根治疗慢性肾小球肾炎作用机制的可视化分析[J]. 山东科学, 2022, 35(4): 58-67.

ZHU Xiao-li, GAO Jia-rong, SHI Miao-miao, QIN Xiu-juan, WEI Liang-bing, LIU Tao, ZHANG Wei. Visual analysis of the mechanism of Astragali Radix-Imperatae Rhizomain in the treatment of chronic glomerulonephritis[J]. Shandong Science, 2022, 35(4): 58-67.

图/表 10

表1

图1

图2

图3

图4

图5

表2

图6

图7

参考文献 36

[1]	李大凤, 张明霞. 健脾益肾祛瘀泄浊方对慢性肾小球肾炎患者肾功能及蛋白尿的影响研究[J]. 中药材, 2014, 37(1):169-171. DOI: 10.13863/j.issn1001-4454.2014.01.013. doi: 10.13863/j.issn1001-4454.2014.01.013
[2]	海江, 刘芳. 参芪地黄汤治疗慢性肾小球肾炎气阴两虚证临床疗效及对免疫功能影响[J]. 辽宁中医药大学学报, 2021, 23(7):131-134. DOI: 10.13194/j.issn.1673-842x.2021.07.027. doi: 10.13194/j.issn.1673-842x.2021.07.027
[3]	LIM W H, WONG G, MCDONALD S P, et al. Long-term outcomes of kidney transplant recipients with end-stage kidney disease attributed to presumed/advanced glomerulonephritis or unknown cause[J]. Scientific Reports, 2018, 8:9021. DOI: 10.1038/s41598-018-27151-4. doi: 10.1038/s41598-018-27151-4
[4]	叶茜, 李玲, 孔薇. 孔薇治疗慢性肾炎经验[J]. 湖南中医杂志, 2021, 37(1):23-25. DOI: 10.16808/j.cnki.issn1003-7705.2021.01.007. doi: 10.16808/j.cnki.issn1003-7705.2021.01.007
[5]	赵琳娜, 刘丽, 李洪艳, 等. 昆仙胶囊治疗慢性肾炎的疗效及免疫机制研究[J]. 中国中西医结合肾病杂志, 2021, 22(4):332-334.
[6]	KASAP B, CARMAN K B, YIS U. A case of acute post-streptococcal glomerulonephritis that developed posterior reversible encephalopathy syndrome[J]. Türk Pediatri Arşivi, 2015, 49(4):348-352. DOI: 10.5152/tpa.2014.430. doi: 10.5152/tpa.2014.430
[7]	马思佳, 赵明明, 常美莹, 等. 黄芪治疗慢性肾炎中的网络药理学研究[J]. 世界中西医结合杂志, 2020, 15(8):1467-1472. DOI: 10.13935/j.cnki.sjzx.200822. doi: 10.13935/j.cnki.sjzx.200822
[8]	沈良兰. 黄芪注射液治疗狼疮性肾炎的临证体会[J]. 中国中西医结合肾病杂志, 2003, 4(7):419-420.
[9]	白玉新, 傅亮, 高进. 黄芪对缺血性急性肾功能衰竭的保护作用[J]. 中国实验方剂学杂志, 2009, 15(7):74-76. DOI: 10.13422/j.cnki.syfjx.2009.07.037. doi: 10.13422/j.cnki.syfjx.2009.07.037
[10]	桂定坤, 顾勇, 彭艾, 等. 黄芪水提物对健康人尿钠排泄的影响及机制研究[J]. 中华肾脏病杂志, 2007(4):214-218. DOI: 10.3760/j.issn:1001-7097.2007.04.003. doi: 10.3760/j.issn:1001-7097.2007.04.003
[11]	燕玉军. 小蓟白茅根藕节治疗慢性肾小球肾炎血尿蛋白尿临床疗效[J]. 光明中医, 2017, 32(4):539-541.
[12]	陈兰英, 陈卓, 王昌芹, 等. 白茅根不同提取物对阿霉素肾病大鼠的保护作用及对TGF-β₁、NF-κB p65分子表达的影响[J]. 中药材, 2015, 38(11):2342-2347. DOI: 10.13863/j.issn1001-4454.2015.11.027. doi: 10.13863/j.issn1001-4454.2015.11.027
[13]	许博文, 吴静远, 李杰, 等. 基于网络药理学探讨百合乌药方治疗胃癌的分子生物学机制[J]. 中国医院药学杂志, 2021, 41(5):442-449. DOI: 10.13286/j.1001-5213.2021.05.02. doi: 10.13286/j.1001-5213.2021.05.02
[14]	吴朗杰, 赵春燕, 战丽彬. 基于网络药理学和分子对接研究白花蛇舌草和半枝莲药对治疗宫颈癌的作用机制[J]. 中草药, 2021, 52(4):1049-1058.
[15]	RU J L, LI P, WANG J N, et al. TCMSP:a database of systems pharmacology for drug discovery from herbal medicines[J]. Journal of Cheminformatics, 2014, 6:13. DOI: 10.1186/1758-2946-6-13. doi: 10.1186/1758-2946-6-13
[16]	LIU Z Y, GUO F F, WANG Y, et al. BATMAN-TCM:a bioinformatics analysis tool for molecular mechANism of traditional Chinese medicine[J]. Scientific Reports, 2016, 6:21146. DOI: 10.1038/srep21146. doi: 10.1038/srep21146
[17]	BREUZA L, POUX S, ESTREICHER A, et al. The UniProtKB guide to the human proteome[J]. Database, 2016, 2016:bav120. DOI: 10.1093/database/bav120. doi: 10.1093/database/bav120
[18]	LI W H, HAN J R, REN P P, et al. Exploration of the mechanism of Zisheng Shenqi decoction against gout arthritis using network pharmacology[J]. Computational Biology and Chemistry, 2021, 90:107358. DOI: 10.1016/j.compbiolchem.2020.107358. doi: 10.1016/j.compbiolchem.2020.107358
[19]	STELZER G, ROSEN N, PLASCHKES I, et al. The GeneCardssuite:From gene data mining to disease genome sequence analyses[EB/OL]. [2021-05-12]. https://doi.org/10.1002/cpbi.5.
[20]	AMBERGER J S, HAMOSH A. Searching online Mendelian inheritance in man (OMIM):a knowledgebase of human genes and genetic phenotypes[EB/OL]. [2021-05-12]. https://doi.org/10.1002/cpbi.27.
[21]	PIÑERO J, RAMÍREZ-ANGUITA J M, SAÜCH-PITARCH J, et al. The DisGeNET knowledge platform for disease genomics:2019 update[J]. Nucleic Acids Research, 2020, 48(D1):D845-D855. DOI: 10.1093/nar/gkz1021. doi: 10.1093/nar/gkz1021
[22]	WISHART D S, FEUNANG Y D, GUO A C, et al. DrugBank 5.0:a major update to the DrugBank database for 2018[J]. Nucleic Acids Research, 2018, 46(D1):D1074-D1082. DOI: 10.1093/nar/gkx1037. doi: 10.1093/nar/gkx1037
[23]	GUO S Y, WU J R, ZHOU W, et al. Investigating the multi-target pharmacological mechanism of Danhong injection acting on unstable angina by combined network pharmacology and molecular docking[J]. BMC Complementary Medicine and Therapies, 2020, 20(1):1-14. DOI: 10.1186/s12906-020-2853-5. doi: 10.1186/s12906-020-2853-5
[24]	SZKLARCZYK D, MORRIS J H, COOK H, et al. The STRING database in 2017:quality-controlled protein-protein association networks, made broadly accessible[J]. Nucleic Acids Research, 2017, 45(D1):D362-D368. DOI: 10.1093/nar/gkw937. doi: 10.1093/nar/gkw937
[25]	ZENG Q, LI L F, JIN Y, et al. A network pharmacology approach to reveal the underlying mechanisms of Paeonia lactiflora pall. on the treatment of Alzheimer's disease[J]. Evidence-Based Complementary and Alternative Medicine, 2019, 2019:1-12. DOI: 10.1155/2019/8706589. doi: 10.1155/2019/8706589
[26]	FAN Y H, LIU W, JIN Y, et al. Integrated molecular docking with network pharmacology to reveal the molecular mechanism of simiao powder in the treatment of acute gouty arthritis[J]. Evidence-Based Complementary and Alternative Medicine, 2021, 2021:1-15. DOI: 10.1155/2021/5570968. doi: 10.1155/2021/5570968
[27]	GUPTA A, BHALLA K, NANDA S, et al. Epidemiology and clinical outcomes of acute glomerulonephritis in a teaching hospital in North India[J]. Journal of Family Medicine and Primary Care, 2019, 8(3):934. DOI: 10.4103/jfmpc.jfmpc_57_19. doi: 10.4103/jfmpc.jfmpc_57_19
[28]	LIU B H, LIN J, BAI L X, et al. Paeoniflorin inhibits mesangial cell proliferation and inflammatory response in rats with mesangial proliferative glomerulonephritis through PI3K/AKT/GSK-3β pathway[J]. Frontiers in Pharmacology, 2019, 10:978. DOI: 10.3389/fphar.2019.00978. doi: 10.3389/fphar.2019.00978
[29]	YUAN K, ZHU Q Q, LU Q Y, et al. Quercetin alleviates rheumatoid arthritis by inhibiting neutrophil inflammatory activities[J]. The Journal of Nutritional Biochemistry, 2020, 84:108454. DOI: 10.1016/j.jnutbio.2020.108454. doi: 10.1016/j.jnutbio.2020.108454
[30]	LIU Y, YU C, JI K, et al. Quercetin reduces TNF-α-induced mesangial cell proliferation and inhibits PTX3 production:involvement of NF-κB signaling pathway[J]. Phytotherapy Research, 2019, 33(9):2401-2408. DOI: 10.1002/ptr.6430. doi: 10.1002/ptr.6430
[31]	ISHIKAWA Y, KITAMURA M. Bioflavonoid quercetin inhibits mitosis and apoptosis of glomerular cells in vitro and in vivo[J]. Biochemical and Biophysical Research Communications, 2000, 279(2):629-634. DOI: 10.1006/bbrc.2000.4016. doi: 10.1006/bbrc.2000.4016
[32]	ZHU S, QIAN Y C. IL-17/IL-17 receptor system in autoimmune disease:mechanisms and therapeutic potential[J]. Clinical Science, 2012, 122(11):487-511. DOI: 10.1042/cs20110496. doi: 10.1042/cs20110496
[33]	LU R R, CHEN J Q, LIU B H, et al. Protective role of Astragaloside IV in chronic glomerulonephritis by activating autophagy through PI3K / AKT / AS160 pathway[J]. Phytotherapy Research, 2020, 34(12):3236-3248. DOI: 10.1002/ptr.6772. doi: 10.1002/ptr.6772
[34]	张晓雪, 王璐瑶, 尚进, 等. 高糖环境下趋化素与其受体ChemR23通过活化p38 MAPK促进肾小球内皮细胞炎性因子IL-6、TNF-α的表达[J]. 中华肾脏病杂志, 2017, 33(7):524-530. DOI: 10.3760/cma.j.issn.1001-7097.2017.07.007. doi: 10.3760/cma.j.issn.1001-7097.2017.07.007
[35]	LI S, ZHANG B. Traditional Chinese medicine network pharmacology:Theory, methodology and application[J]. Chinese Journal of Natural Medicines, 2013, 11(2):110-120. DOI:10.1016/S1875-5364(13)60037-0.
[36]	CHEBOTAREVA N V, VINOGRADOV A A, GINDIS A A, et al. The balance of proinflammatory cytokines and Treg cells in chronic glomerulonephritis[J]. Terapevticheskii Arkhiv, 2020, 92(6):46-52. DOI: 10.26442/00403660.2020.06.000671. doi: 10.26442/00403660.2020.06.000671

成分ID	成分	OB/%	DL	药物
MOL000098	槲皮素	46.43	0.28	黄芪
MOL000392	芒柄花黄素	69.67	0.21	黄芪
MOL000354	异鼠李素	49.6	0.31	黄芪
MOL000239	华良姜素	50.83	0.29	黄芪
MOL000371	3,9-二-O-甲基紫檀酚	53.74	0.48	黄芪
MOL000378	7-O-甲基-异微凸剑叶莎醇	74.69	0.30	黄芪
MOL000296	常春藤皂甙元	36.91	0.75	黄芪
MOL000211	白桦脂酸	55.38	0.78	黄芪
MOL000033	β-谷甾醇	36.23	0.78	黄芪
MOL000359	谷甾醇	36.91	0.75	黄芪

通路ID	通路	KEGG分类	P值	背景基因数	前景基因数
ko04933	AGE-RAGE信号通路在糖尿病并发症中的应用	内分泌和代谢性疾病	1.17×10^-33	114	33
ko05200	癌症中的途径	癌症	5.26×10^-33	550	57
ko05418	流体剪切应力和动脉粥样硬化	心血管疾病	4.48×10^-28	149	32
ko05161	乙型肝炎	传染性疾病	9.87×10^-26	160	31
ko04657	IL-17信号传导途径	免疫系统	1.03×10^-21	106	24
ko04668	TNF信号传导途径	信号转导	1.01×10^-20	130	25
ko05215	前列腺癌	癌症	2.91×10^-18	101	21
ko05142	恰加斯病(美洲锥虫病)	传染性疾病	3.54×10^-18	116	22
ko05167	卡波西肉瘤相关的疱疹病毒感染	传染性疾病	4.53×10^-18	241	29
ko05219	膀胱癌	癌症	4.74×10^-17	43	15
