基于网络药理学探讨金荞麦抗呼吸道合胞病毒作用机制

doi:10.3976/j.issn.1002-4026.2022.04.005

山东科学 ›› 2022, Vol. 35 ›› Issue (4): 28-37.doi: 10.3976/j.issn.1002-4026.2022.04.005

基于网络药理学探讨金荞麦抗呼吸道合胞病毒作用机制

杜海涛¹^,²(), 王平¹^,³^,^*(), 李娜², 韩莉¹, 丁洁², 胡亚楠²

1. 山东省中医药研究院,山东济南 250014
2. 山东中医药大学药学院,山东济南 250355
3. 天津大学精密测试技术及仪器国家重点实验室,天津 300072

收稿日期:2021-07-21 出版日期:2022-08-20 发布日期:2022-07-25
通信作者: 王平 E-mail:kkitdht@foxmail.com;wangpingjinan@163.com
作者简介:杜海涛(1996—),男,硕士,研究方向为中药药理学。E-mail: kkitdht@foxmail.com
基金资助:
山东省重大科技创新工程(2018CXGC1310);山东省重大科技创新工程(2020CXGC010505-04);山东省高校中药质量控制与全产业链建设协同创新中心项目(CYLXTCX2020-04);山东省高校中药质量控制与全产业链建设协同创新中心项目(CYLXTCX2021-01);山东省自然科学基金(ZR2020MH386);山东省自然科学基金(ZR2019MH134);政府间国际科技创新合作项目(2019YFE0117800);中央引导地方项目(YDZX20203700002055);泰山学者工程项目(ts201511074);全国中医药创新骨干人才培养项目

The mechanism underlying Fagopyri Dibotryis Rhizoma's action against respiratory syncytial virus using network pharmacology

DU Hai-tao¹^,²(), WANG Ping¹^,³^,^*(), LI Na², HAN Li¹, DING Jie², HU Ya-nan²

1. Shandong Academy of Chinese Medicine, Jinan 250014, China
2. School of Pharmaceutical Sciences, Shandong University of Traditional Chinese Medicine, Jinan 250355, China
3. State Key Laboratory of Precision Measurement Technology and Instruments, Tianjin University, Tianjin 300072, China

Received:2021-07-21 Online:2022-08-20 Published:2022-07-25
Contact: WANG Ping E-mail:kkitdht@foxmail.com;wangpingjinan@163.com

摘要/Abstract

摘要：

基于网络药理学筛选金荞麦抗呼吸道合胞病毒的核心作用成分及靶点,并使用芯片数据挖掘和分子对接做初步验证。通过中药系统药理学数据库与分析平台(traditional Chinese medicine systems pharmacology database and analysis platform,TCMSP)筛选核心作用成分,借助SwissTargetPrediction预测核心作用成分靶点,通过GeneCards、GenCLiP 3、NCBI获取呼吸道合胞病毒涉及肺炎靶点。经靶点映射生成交集靶点网络,并通过STRING、DAVID平台构建蛋白质-蛋白质相互作用(Protein-protein interaction,PPI)关系及核心富集通路,获取核心靶点与通路。使用GEO芯片数据挖掘及AutoDock Vina分子对接初步验证核心靶点的有效性。最终通过TCMSP筛选到金荞麦15个成分,经靶点映射发现金荞麦通过45个靶点发挥作用,通过PPI和KEGG(Kyoto encyclopedia of genes and genomes) 通路综合分析可得金荞麦发挥抗呼吸道合胞病毒的作用靶点为AKT1、VEGFA、PTGS2、SRC、EGFR、KDR、STAT3、BCL2等,数据挖掘和分子对接结果与预测基本一致,为进一步深入揭示其作用机制奠定了良好基础。

关键词: 网络药理学, 分子对接, 靶点, 呼吸道合胞病毒, 金荞麦

Abstract:

The core ingredients and targets of Fagopyri Dibotryis Rhizoma against respiratory syncytial virus (RSV) were screened using network pharmacology and verified via gene chip mining and molecular docking. The core ingredients were screened using the traditional Chinese medicine systems pharmacology database(TCMSP), targets of the core ingredients were predicted using SwissTargetPrediction, and targets of pneumonia-causing RSV were obtained using GeneCards, GenCLiP 3, and National Center for Biotechnology Information database. The intersection target network was generated via target mapping, and the protein-protein interaction (PPI) network and core enrichment Kyoto encyclopedia of genes and genomes (KEGG) pathway were constructed through STRING and DAVID platforms to obtain the core targets and pathways. Gene expression omnibus chip data mining and AutoDock Vina molecular docking were used to verify the effectiveness of the core targets. Fifteen components of Fagopyri Dibotryis Rhizoma were screened using TCMSP database. Furthermore, target mapping showed that Fagopyri Dibotryis Rhizoma had 45 targets. Through the comprehensive analysis of PPI network and KEGG pathway, the targets of Fagopyri Dibotryis Rhizoma against RSV were found to be AKT1, VEGFA, PTGS2, SRC, EGFR, KDR, STAT3, BCL2,etc. The results of data mining and molecular docking were basically consistent with the prediction. This study preliminarily predicted the main active components, targets, and related pathways of Fagopyri Dibotryis Rhizoma, which would prove to be beneficial in the treatment of RSV-induced diseases, and laid a good foundation for further revealing its mechanism.

Key words: network pharmacology, molecular docking, targets, respiratory syncytial virus, Fagopyri Dibotryis Rhizoma

中图分类号:

R285.5

杜海涛, 王平, 李娜, 韩莉, 丁洁, 胡亚楠. 基于网络药理学探讨金荞麦抗呼吸道合胞病毒作用机制[J]. 山东科学, 2022, 35(4): 28-37.

DU Hai-tao, WANG Ping, LI Na, HAN Li, DING Jie, HU Ya-nan. The mechanism underlying Fagopyri Dibotryis Rhizoma's action against respiratory syncytial virus using network pharmacology[J]. Shandong Science, 2022, 35(4): 28-37.

图/表 9

表1

图1

图2

图3

图4

图5

图6

图7

图8

参考文献 34

[1]	SHI T, MCALLISTER D A, O'BRIEN K L, et al. Global, regional, and national disease burden estimates of acute lower respiratory infections due to respiratory syncytial virus in young children in 2015:A systematic review and modelling study[J]. The Lancet, 2017, 390(10098):946-958. DOI:10.1016/S0140-6736(17)30938-8. doi: 10.1016/S0140-6736(17)30938-8
[2]	杜海涛, 孙铁锋, 王平, 等. 清热药抗呼吸道合胞病毒的研究进展[J]. 中成药, 2019, 41(10):2435-2441.
[3]	WANG G Y, DEVAL J, HONG J, et al. Discovery of 4'-Chloromethyl-2'-deoxy-3', 5'-di-O-isobutyryl-2'-fluorocytidine (ALS-8176), A First-in-Class rsv polymerase inhibitor for treatment of human respiratory syncytial virus infection[J]. Journal of Medicinal Chemistry, 2015, 58(4):1862-1878. DOI: 10.1021/jm5017279. doi: 10.1021/jm5017279
[4]	FRIEDMAN N, ALTER H, HINDIYEH M, et al. Human Coronavirus Infections in Israel:Epidemiology, Clinical Symptoms and Summer Seasonality of HCoV-HKU1[J]. Viruses, 2018, 10(10) :515. DOI: 10.3390/v10100515. doi: 10.3390/v10100515
[5]	RUCKWARDT T J, MORABITO K M, GRAHAM B S. Immunological lessons from respiratory syncytial virus vaccine development[J]. Immunity, 2019, 51(3):429-442. DOI: 10.1016/j.immuni.2019.08.007. doi: 10.1016/j.immuni.2019.08.007
[6]	严晶, 袁嘉嘉, 刘丽娜, 等. 金荞麦药理作用及临床应用研究进展[J]. 山东中医杂志, 2017, 36(7):621-624. DOI: 10.16295/j.cnki.0257-358x.2017.07.026. doi: 10.16295/j.cnki.0257-358x.2017.07.026
[7]	赵炎军, 刘园, 谢升阳, 等. 金荞麦提取物体外抗流感病毒作用研究[J]. 中国现代应用药学, 2019, 36(21):2648-2651. DOI: 10.13748/j.cnki.issn1007-7693.2019.21.005. doi: 10.13748/j.cnki.issn1007-7693.2019.21.005
[8]	杨玺文, 张燕, 李隆云. 药用植物金荞麦研究进展[J]. 中国现代中药, 2019, 21(6):837-846. DOI: 10.13313/j.issn.1673-4890.20180709003. doi: 10.13313/j.issn.1673-4890.20180709003
[9]	PRADO-PRADO F J, URIARTE E, BORGES F, et al. Multi-target spectral moments for QSAR and Complex Networks study of antibacterial drugs[J]. European Journal of Medicinal Chemistry, 2009, 44(11):4516-4521. DOI: 10.1016/j.ejmech.2009.06.018. doi: 10.1016/j.ejmech.2009.06.018
[10]	CALZOLAI L, ANSORGE W, CALABRESE E, et al. Transcriptomics and proteomics. Applications to ecotoxicology[J]. Comparative Biochemistry and Physiology Part D:Genomics and Proteomics, 2007, 2(3):245-249. DOI: 10.1016/j.cbd.2007.04.007. doi: 10.1016/j.cbd.2007.04.007
[11]	姚文博, 李丰, 石彬彬, 等. 系统药理学Ⅲ:在诠释中医药整体作用机制中的应用进展[J]. 中国实验方剂学杂志, 2020, 26(13):219-227.DOI: 10.13422/j.cnki.syfjx.20200655. doi: 10.13422/j.cnki.syfjx.20200655
[12]	张彦琼, 李梢. 网络药理学与中医药现代研究的若干进展[J]. 中国药理学与毒理学杂志, 2015, 29(6):883-892. DOI: 10.3867/j.issn.1000-3002.2015.06.002. doi: 10.3867/j.issn.1000-3002.2015.06.002
[13]	RU J L, LI P, WANG J N, et al. TCMSP:a database of systems pharmacology for drug discovery from herbal medicines[J]. Journal of Cheminformatics, 2014, 6:13. DOI: 10.1186/1758-2946-6-13. doi: 10.1186/1758-2946-6-13
[14]	LI J S, ZHAO P, LI Y, et al. Systems pharmacology-based dissection of mechanisms of Chinese medicinal formula Bufei Yishen as an effective treatment for chronic obstructive pulmonary disease[J]. Scientific Reports, 2015, 5:15290. DOI: 10.1038/srep15290. doi: 10.1038/srep15290
[15]	GFELLER D, MICHIELIN O, ZOETE V. Shaping the interaction landscape of bioactive molecules[J]. Bioinformatics, 2013, 29(23):3073-3079. DOI: 10.1093/bioinformatics/btt540. doi: 10.1093/bioinformatics/btt540
[16]	VON MERING C, JENSEN L J, SNEL B, et al. STRING:known and predicted protein-protein associations, integrated and transferred across organisms[J]. Nucleic Acids Research, 2005, 33(Database issue):D433-D437. DOI: 10.1093/nar/gki005. doi: 10.1093/nar/gki005
[17]	LIU J L, LIU J J, SHEN F X, et al. Systems pharmacology analysis of synergy of TCM:An example using saffron formula[J]. Scientific Reports, 2018, 8(1):380. DOI: 10.1038/s41598-017-18764-2. doi: 10.1038/s41598-017-18764-2
[18]	MOMOTA R, OHTSUKA A. Network of anatomical texts (NAnaTex), an open-source project for visualizing the interaction between anatomical terms[J]. Anatomical Science International, 2018, 93(1):149-153. DOI: 10.1007/s12565-017-0410-1. doi: 10.1007/s12565-017-0410-1
[19]	LI S, ZHANG Z Q, WU L J, et al. Understanding ZHENG in traditional Chinese medicine in the context of neuro-endocrine-immune network[J]. IET Systems Biology, 2007, 1(1):51-60. DOI: 10.1049/iet-syb:20060032. doi: 10.1049/iet-syb:20060032
[20]	IOANNIDIS I, MCNALLY B, WILLETTE M, et al. Plasticity and virus specificity of the airway epithelial cell immune response during respiratory virus infection[J]. Journal of Virology, 2012, 86(10):5422-5436. DOI: 10.1128/JVI.06757-11. doi: 10.1128/JVI.06757-11
[21]	BENJAMINI Y, HOCHBERG Y. Controlling the false discovery rate:a practical and powerful approach to multiple testing[J]. Journal of the Royal Statistical Society:Series B (Methodological), 1995, 57(1):289-300. DOI: 10.1111/j.2517-6161.1995.tb02031.x. doi: 10.1111/j.2517-6161.1995.tb02031.x.
[22]	JO S, KIM S, SHIN D H, et al. Inhibition of SARS-CoV 3CL protease by flavonoids[J]. Journal of Enzyme Inhibition and Medicinal Chemistry, 2020, 35(1):145-151. DOI: 10.1080/14756366.2019.1690480. doi: 10.1080/14756366.2019.1690480
[23]	王登嵘, 刘显, 肖健. Src蛋白激酶在疾病中的功能及研究现状[J]. 医学与哲学(B), 2018, 39(1):58-60.
[24]	张佳鑫, 蒋一凡, 雷昕诺, 等. Src和Abl酪氨酸蛋白激酶家族参与病原微生物感染的研究进展[J]. 微生物学通报, 2019, 46(10):2781-2786. DOI: 10.13344/j.microbiol.china.180793. doi: 10.13344/j.microbiol.china.180793
[25]	郑刚. Src同源磷酸酪氨酸磷酸酶2促进α-干扰素诱导的jak/stat1信号通路从而抑制呼吸道合胞病毒复制[D]. 杭州: 浙江大学, 2015.
[26]	RATTANAMAHAPHOOM J, LEAUNGWUTIWONG P, LIMKITTIKUL K, et al. Activation of dengue virus-specific T cells modulates vascular endothelial growth factor receptor 2 expression[J]. Asian Pacific Journal of Allergy and Immunology, 2017, 35(3):171-178. DOI: 10.12932/ap0810. doi: 10.12932/ap0810
[27]	DARNELL J E, KERR I M, STARK G R. Jak-STAT pathways and transcriptional activation in response to IFNs and other extracellular signaling proteins[J]. Science, 1994, 264(5164):1415-1421. DOI: 10.1126/science.8197455. doi: 10.1126/science.8197455
[28]	汤波, 韦佳佳, 徐丙发, 等. STAT1修饰对干扰素抗乙肝病毒作用影响的研究进展[J]. 安徽医科大学学报, 2017, 52(4):615-618. DOI: 10.19405/j.cnki.issn1000-1492.2017.04.035. doi: 10.19405/j.cnki.issn1000-1492.2017.04.035
[29]	KVANSAKUL M, CARIA S, HINDS M. The bcl-2 family in host-virus interactions[J]. Viruses, 2017, 9(10):290. DOI: 10.3390/v9100290. doi: 10.3390/v9100290
[30]	THOMAS K W, MONICK M M, STABER J M, et al. Respiratory syncytial virus inhibits apoptosis and induces NF-κB activity through a phosphatidylinositol 3-kinase-dependent pathway[J]. Journal of Biological Chemistry, 2002, 277(1):492-501. DOI: 10.1074/jbc.M108107200. doi: 10.1074/jbc.M108107200
[31]	MONICK M M, CAMERON K, POWERS L S, et al. Sphingosine kinase mediates activation of extracellular signal-related kinase and Akt by respiratory syncytial virus[J]. American Journal of Respiratory Cell and Molecular Biology, 2004, 30(6):844-852. DOI: 10.1165/rcmb.2003-0424OC. doi: 10.1165/rcmb.2003-0424OC
[32]	BONSER L R, ERLE D J. Airway Mucus and Asthma:the role of MUC5AC and MUC5B[J]. Journal Clinical Medicine, 2017, 6(12):112. DOI: 10.3390/jcm6120112. doi: 10.3390/jcm6120112
[33]	CURRIER M G, LEE S, STOBART C C, et al. EGFR interacts with the fusion protein of respiratory syncytial virus strain 2-20 and mediates infection and mucin expression[J]. PLoS Pathogens, 2016, 12(5):e1005622. DOI: 10.1371/journal.ppat.1005622. doi: 10.1371/journal.ppat.1005622
[34]	刘娟娟, 张婷, 米芋枚. 呼吸道合胞病毒感染对气道上皮细胞表皮生长因子受体、紧密连接相关蛋白及黏蛋白表达的影响[J]. 中国当代儿科杂志, 2019, 21(3):294-299.

NO	英文名	中文名	归类	Mol ID	分子量
01	Quercetin	槲皮素	黄酮	MOL000098	302.25
02	Eriodyctiol	圣草酚	黄酮	MOL002914	288.27
03	Isorhamnetin	异鼠李素	黄酮	MOL000354	316.28
04	Beta-sitosterol	β-谷甾醇	甾体	MOL000358	414.79
05	Sitosterol	谷甾醇	甾体	MOL000359	414.79
06	Procyanidin B1	原花青素B1	黄酮	MOL000004	578.56
07	(+)-Catechin	(+)-儿茶素	黄酮	MOL000492	290.29
08	Digallate	二没食子酸	鞣质	MOL000569	322.24
09	Luteolin	木犀草素	黄酮	MOL000006	286.25
10	Coumaroyltyramine	辣椒碱	酰胺	MOL000631	283.35
11	(-)-Catechin gallate	(-)-儿茶素没食子酸酯	黄酮	MOL006504	442.40
12	3-Methylquercetin	3-甲基槲皮素	黄酮	MOL007280	316.28
13	(-)-Epicatechin	(-)-表儿茶素	黄酮	MOL000073	290.29
14	3,8-dihydroxy-10-methoxy-5-h-isochromeno [4,,3-b]chromen-7-one	3,8-二羟基-10-甲氧基-5-h- 异色烯[4,3-b]色烯-7-酮	黄酮	MOL007301	312.29
15	(-)-catechin	(-)-儿茶素	黄酮	MOL000096	290.29
